Standrd: IEC1008, GB 16916, BS EN61008
Rated Voltage(Un): 2pole:230V AC 4pole: 400V AC
Rated Current(In):25,40,63A
Rated residual operating current(I△n):30,100,300,500mA
Rated residual non-operating current(I△no):0.51△n
Ressidual current off-time:≤0.1S
Minimum ＆#118alue of rated making and breaking capacity(Im):500A
Rated conditional short-circuit current(Inc):3KA
Installation: On symmetrical DIN rail
