Breaking capacity

B

N

S

H

X

Rated current of frame size      Inm

160

Rated current                         In

12.5,16,20,25, (30),32,40,50,(60),63,80,100,125,(150),160

12.5,16,20,25,32,40,

50,63,80,100,(125)

Rated insulation voltage            Ui

690V

Rated operating voltage            Ue

400V

Number of poles

3

Icu 400V/50HZ 0-CO  KA

Rated ultimate short-circuit breaking capacity

20

35

50

50

70

Ics 400V/50HZ O-CO-COKARated service short-circuit breaking capacity

10

17.5

37.5

37.5

52.5

  Icm 400V/50HZ 0-CO   KA

Rated short-circuit making capacity

40/0.3

74/0.25

105/0.25

105/0.25

154

Uimp                     V

Rated impulse withstand voltage

8000

Dielectric property                  V

3000

Endurance

Total cycles

8000

Electrical endurance

1000

Mechanical endurance

7000

Ionization distance                 (mm)

≤30/0

Over current trip unit

Thermal magnetic release

Intelligent trip unit

Utilization category

Main circuit

A

Auxiliary circuit

AC-15

Outline dimensions

W(mm)

90            90

L(mm)

120            120

H(mm)

70              82
