Product
|
Requirements
|
Model 1
|
Model 2
|
Model 3
|
Model 4
|
Model 5
|
|
Power (VA)
|
PCT-500
|
PCT-650
|
PCT-1000
|
PCT-1500
|
PCT-2000
|
|
Input
|
Voltage
|
145-290VAC±5V
|
|
Frequency
|
50Hz+/-10%
|
|
Output
|
Voltage (AC Mode)
|
190-250VAC
|
|
Voltage (Inverter Mode)
|
220VAC ±5%
|
|
Capacity
|
500VA/300W
|
650VA/360W
|
1000VA/600W
|
1500VA/880W
|
2000VA/1200W
|
|
Frequency (Inverter Mode)
|
50Hz+/-0.5Hz
|
|
Transfer Time
|
2ms typical
|
|
Generator connection
|
Normal Working under the Generator
|
|
Waveform
|
modified-Sinewave
|
|
Protection
|
Spike & Surge Suppression
|
yes
|
|
Over/Under Volt.
|
Switch to Bat. O / P when Mains over regulation range
|
|
Over load /short Circuit
|
Fuse & current linited for both Mains and Battery modes
|
|
Battery
|
Type
|
Lead-Acid miantenance-free
|
|
Dc Bus
|
12V7.0Ah
|
12V7.0Ah
|
12V9.0Ah
|
12V7.0Ah
|
|
Number
|
1 PC
|
2 PCS
|
|
Recharge time
|
8hours≥90%
|
|
Back up time(one PC)
|
8-15mins
|
10-18mins
|
20-30mins
|
25-45mins
|
30-45mins
|
|
Physical
|
Weight (KGs)
|
5
|
5.5
|
10.5
|
11.5
|
17
|
|
Shipping Wt.
|
5.6
|
6
|
11
|
12
|
18
|
|
Product Dimensions (mm)
|
335*95*160
|
355*120*195
|
410*145*215
|
|
Packing Dimensions (mm)
|
435*395*275/ 2 PCS in 1 Carton
|
435*395*275/ 2 PCS in 1 Carton
|
495*250*335
|
|
Soft ware
|
RS232 or USB option Windows & NT
|
Auto save & shut down
|
|
Function
|
Cold start
|
UPS Start The Computer Even there Is no Main Power
|
|
Automatic Charge
|
Automatic Charge when UPS is off
|
|
Automatic Restart
|
Automatic Restart if main power coming within one hour
|
|
Voltage display
|
220v/230v Optional following the real capacity
|
|
Frequency
|
50HZ/60HZ Optioanl following the real
|
|
Beeping
|
During the battery mode ,the beeping optional
|
|
Efficiency
|
AC-AC
|
1
|
|
DC-AC
|
0.6
|
|
Acoustic
|
Noise level
|
≤45dB
|
|
Environmental
|
Temperature
|
-5-45 DegreeC
|
|
Humidity
|
20% to 90%
|
|
Power Outlets
|
No. and types
|
2 SOCKETS
|
3 SOCKETS
|
4 SOCKETS
|
