| Main Features | ||||
| ●Micro Processsor Control | ||||
| ●User selectable for accepting wider input voltage | ||||
| ●Full automatic and silient operation | ||||
| ●Automatic Line-to-Battery Switch over | ||||
| ●Intelligent Automatic Charging Technology | ||||
| ●Rack and Tower design | ||||
| ●Automatic charge while AC recovery(off model charging) | ||||
| ●High Efficient DC-to-AC conversion.minimizing energy loss | ||||
| ●Over load，short circuit protection | ||||
| ●Low battery protection | ||||
| ●Cool start | ||||
| ●Isolated output | ||||
| ●Compatibility with generators | ||||
| ●Multi-function LED Display Design and buzzer alarms. | ||||
| ●Application for Fan, light ,TV and office Appliances | ||||
| Overview | ||||
|
MODEL |
SKN-H600 |
SKN-H1000 |
SKN-H1000 |
SKN-H2000 |
|
SPECIFICATION |
||||
|
DC INPUT |
||||
|
Input Voltage(Vdc) |
12 |
12 |
24 |
24 |
|
Input DC Range(Vdc) |
10~15 |
20~30 |
||
|
AC Bypass in “on/off” switch off mode |
||||
|
Input AC Range(Vac) |
110/120VAC or 120/230/240VAC |
|||
|
90-145VAC or 170-280VAC(Narrow Range) |
||||
|
50-145VAC or 90-280VAC (Wide Range) |
||||
|
Input Frequency(Hz) |
50/60 HZ |
|||
|
Bypass Output Voltage(Vac) |
SAME AS INPUT AC |
|||
|
Bypass Output Frequency(Hz) |
SAME AS INPUT Frequency |
|||
|
Charge Current(A) |
10A±2A |
|||
|
Charge Floating Voltage(V) |
13.75±0.2V |
27.5±0.4V |
||
|
Over Charge Voltage(V) |
15.0V±0.4V Charge stop |
30.0V±0.8V Charge stop |
||
|
AC Efficiency |
> 97% |
|||
|
Transfer Time(ms) |
Typical 10ms |
|||
|
AC OUTPUT (INVERTER) |
||||
|
Capacity(VA) |
600 |
1000 |
1000 |
2000 |
|
Output Power(W) |
360 |
600 |
600 |
1200 |
|
Output Voltage |
110/220VAC |
|||
|
Output Frequency |
50/60HZ |
|||
|
Output Current(A) |
2.7/1.6 |
4.5/2.7 |
4.5/2.7 |
9.1/5.5 |
|
Voltage Precision(VAC) |
110/220±10% |
|||
|
Frequency Precision(HZ) |
50/60Hz±0.1HZ |
|||
|
Wave |
modify sine wave |
|||
|
Power Factor(PF) |
0.6 |
|||
|
Inversion Efficiency |
>85% |
|||
|
Bypass Transfer time(ms) |
<=8 ms |
|||
|
Over load capacity |
over load 110%,60s later shut offer |
|||
|
PROTECTION |
||||
|
Protection |
over load/ short circuit protection |
|||
|
Over charge , discharge protection |
||||
|
AMBIENT |
||||
|
Noise(dB) |
<=40 (1 mter) |
|||
|
Temperature |
-20~45 degree |
|||
|
Humidity |
0~95% ( no condensation) |
|||
|
Sea Level(m) |
<=1500 |
|||
|
DIMENSION |
||||
|
Package L×W×H(mm) |
350*128*310 |
|||
|
Weight(Kg) |
3.1 |
3.6 |
3.3 |
3.9 |
